JL3TF30/31 magnetic ac contactors 1N.O+1N.C

Short Description:

Disposal

Siemens products are environment friendly, which predominantly consist of recyclable material for disposal we recommend disassembling and separation into following materials

Metal:Segregate into ferrous & non ferrous types for recycling through author land dealer

Plastic: Segregate as per material type for recycling through author land dealer because of the long life time of Siemens products the disposal guidelines may be replaced by other national regulations when taking the products out of service. The local customer care service is available at any time to answer disposal-related questions


Product Detail

Product Tags

Codes for AC coils

Voltage(V) 24 42 48 110 230 380 415 others
Code B0 D0 H0 F0 P0 Q0 R0 On enquiry

ON/OFF Indication

.Installation:

Mounting dimensions (mm)

Allowable conductor sizes:

Permissible cross-sections for main auxiliary conductors solid

Finely stranded with end sleeve          2×0.5 to 1mm

AWG wires:                          2 x 1 to 2.5mm

Tightening torque standard type:         1x 4mm

                                    2x 0.75 to 2.5mm

                                    2x AWG 18-12

                                    0.8 to 1.4Nm/7 to 12 Lb-in

Tightening torque auxiliary contact block   0.8 to 1.1Nm/7 to 12Lb-in

Circuit diagrams:

.Maintenance:

Remove dust by section, discolored and rough contacts are still service worthy and should not be filed or greased

Replacement of the contacts is not recommended

Auxiliary contact block replacement(Common for AC contactor and DC contactor)
