Big Power AC Contactor JLC1-F 115A~800A 380V

Short Description:

JLC1-F AC contactor is suitable for using in the circuits u to the rated voltage 380V AC 50/60Hz, current 800A, for long distance breaking circuit and frequently starting or controlling the motor. It also can be used for the control of distribution circuits of rated current from 115A to 800A.
It conforms to IEC60947-4-1.


Product Detail

More Description

Product Tags

 Specification

Type AC-3(A)Rated
operational
current in AC-3(A)
Max power ratings of 3-phase motors in Operating
frequency
(time/ hour)
Electrical
lifeAC-3 x104
Mecha- nical
life x104
category AC-3(kW) AC-3
220V
230V
380V
400V
415V 440V 500V 660V 1000V
690V
JLC1-F115 115 30 55 59 59 75 80 65 1200 120 1000
JLC1-F1154 115 30 55 59 59 75 80 65 1200 120 1000
JLC1-F150 150 40 75 80 80 90 100 65 1200 120 1000
JLC1-F1504 150 40 75 80 80 90 100 65 1200 120 1000
JLC1-F185 185 55 90 100 100 110 110 100 600 100 600
JLC1-F1854 185 55 90 100 100 110 110 100 600 100 600
JLC1-F225 225 63 110 110 110 130 129 100 600 100 600
JLC1-F2254 225 63 110 110 110 130 129 100 600 100 600
JLC1-F265 265 75 132 140 140 160 160 147 600 80 600
JLC1-F2654 265 75 132 140 140 160 160 147 600 80 600
JLC1-F330 330 100 160 180 200 200 220 160 600 80 600
JLC1-F3304 330 100 160 180 200 200 220 160 600 80 600
JLC1-F400 400 110 200 220 250 257 280 185 600 80 600
JLC1-F4004 400 110 200 220 250 257 280 185 600 80 600
JLC1-F500 500 147 250 280 295 355 330 315 600 80 600
JLC1-F5004 500 147 250 280 295 355 335 335 600 80 600
JLC1-F630 630 200 335 375 400 400 450 450 600 80 600
JLC1-F6304 630 200 335 375 400 400 450 450 600 80 600
JLC1-F780 780 220 400 425 425 450 470 450 600 80 600
JLC1-F7804 780 220 400 425 425 450 475 450 600 80 600
JLC1-F800 800 250 415 450 450 450 470 450 600 80 600

Outline And Mounting Dimension

product-parameter1
product-parameter2
product-parameter3
JLC1- a b b2 c f G* G min. G
max.
G1 * G1
min.
G1
max.
J L M P Q

Q1

S

2P

213 206 375 219 119 80 66 102 170 156 192 19.5 145 181 48 69

96

25

F400 3P

213 206 375 219 119 80 66 102 170 156 192 19.5 145 181 48 43

74

25

4P

261 206 375 219 119 80 66 150 170 156 240 67.5 145 181 48 43

74

25

2P

233 238 400 232 141 80 66 120 170 156 210 39.5 146 208 55 76

102

30

F500 3P

233 238 400 232 141 80 66 120 170 156 210 39.5 146 208 55 46

77

30

4P

288 238 400 232 141 140 66 175 230 156 265 34.5 146 208 55 46

77

30
product-parameter4
JLC1-F a G G min. G max. J1

Q

Q1
F630 2P 309 180 100 195 68.5

102

127
F630,F800 3P 309 180 100 195 68.5

60

89
F630 4P 389 240 150 275 68.5

60

89
product-parameter5

JLC1-F Bobbin of AC Contactor JLC1-F

product-parameter6
product-parameter7

  • Previous:
  • Next:

  • Contactor production engineering:
    1.Excellent shell material
    2.Cooper part with 85% silver contact point
    3.Standard cooper coil
    4.High quality magnet
    Beautiful packing box

    more-description3

    Application scenarios:
    Usually installed in the distribution box on the floor, computer center,telecommunication room,elevator control room,cable TV room,building control room, fire center, industrial automatic control area, hospital operation room,monitoring room and distribution box equipment with electronic medical device.
